MIDLAND SERIES
24-GAUGE SMOOTH STEEL
The Midland Series offers a reliable choice in commodity doors, featuring a durable 24-gauge smooth steel construction. These doors are designed for practicality and functionality while providing stylish panel designs. The Midland series ensures robust performance without compromising quality, making it an ideal solution for residential and light commercial applications.
Styles
6/8 HEIGHT
FLFlush
1PHD1-Panel Raised
2PHD2-Panel Raised
2PATHD2-Panel Arch Top Raised
2PATPHD2-PANEL ARCH TOP PLANK RAISED
3/4-2PSTHD3/4 2-Panel Raised
3PCRHD3-PANEL CRAFTSMAN RAISED
XBCrossbuck
4PBTHD4-PANEL BLANK TOP RAISED
T4PTRUE 4-PANEL RAISED
5PE5-PANEL HORIZONTAL SHAKER
6PHD6-PANEL RAISED
8P8-PANEL RAISED
8/0 HEIGHT
FLFLUSH
2PHD2-PANEL RAISED
6P6-PANEL RAISED
Specifications
Standard Specifications
| FACE MATERIAL | G40 hot-dipped galvanized steel skin |
|---|---|
| SKIN GAUGE | 24-gauge |
| SKIN SURFACE | Smooth |
| FINISH | Baked-on polyester primer |
| CORE MATERIAL | Injected polyurethane foam core |
| EDGE CONSTRUCTION | Full steel-edge perimeter |
| THICKNESS | 1.720" (nominal 1-3/4") |
| LOCK BLOCK | Composite lock block |
| HINGE REINFORCEMENTS | 20-gauge fixed hinge reinforcement |
| HINGE PREP | 4" surface mount, fixed hinge prep |
AVAILABLE OPTIONS
| HINGE PREP | 4" surface mount, fixed hinge 4" surface mount, adjustable hinge 4" surface mount, template fixed hinge 4-1/2" surface mount, commercial template fixed hinge |
|---|---|
| CLOSER PREP | Steel closer reinforcement plates |
| PANIC PREP | Exit hardware reinforcement |
| ADA COMPLIANCE | 10" ADA bottom rail on specific styles |
Ratings
| FIRE RATING | 20-minute or 90-minute |
|---|---|
| SECURITY TESTING | Grade 40 |
| STC RATING | 22 |
| OITC | 23 |
| U-VALUE | 0.17 |
Warranty
Resources
| Codes Compliance and Testing Documents | |
| ENERGY STAR | |
| Pre-Hung Door Install Guide | |
| Sidelite | Embossment & Lite Cutout Options #V-2 | |
| Sidelite | Embossment Details 24-Gauge Steel #V-3 | |
| Sidelite | Lite Cutout Details 24-Gauge Steel #V-4 | |
| Sidelite | Lite Cutout Details 24-Gauge Steel #V-5 | |
| Sidelite | Lite Cutout Details 24-Gauge Steel #V-6 | |
| Steel Door | Care and Maintenance Guide | |
| Steel Door | Construction #II-1 | |
| Steel Door | Lite Cutout Options #II-21-26 | |
| Steel Door | Residential New Construction Standard #II-2 | |
| Steel Door Embossment | 1-Panel Raised #II-20h | |
| Steel Door Embossment | 2-Panel Arch Top Raised #II-20c | |
| Steel Door Embossment | 2-Panel Arch Top Raised ADA #II-20c | |
| Steel Door Embossment | 2-Panel Raised #II-20a | |
| Steel Door Embossment | 2-Panel Raised 8'0" Height #II-20j | |
| Steel Door Embossment | 2-Panel Raised ADA #II-20a | |
| Steel Door Embossment | 3-Panel Craftsman Raised #II-20g | |
| Steel Door Embossment | 3/4 2-Panel Raised #II-20r | |
| Steel Door Embossment | 4-Panel Blank Top #II-20f | |
| Steel Door Embossment | 4-Panel Blank Top Narrow #II-10 | |
| Steel Door Embossment | 5-Panel Horizontal Shaker #II-20q | |
| Steel Door Embossment | 5-Panel Horizontal Shaker ADA #II-20q | |
| Steel Door Embossment | 6-Panel Raised #II-20e | |
| Steel Door Embossment | 6-Panel Raised 8'0" Height #II-19 | |
| Steel Door Embossment | 6-Panel Raised Narrow #II-14 | |
| Steel Door Embossment | 8-Panel #II-15 | |
| Steel Door Embossment | Crossbuck #II-17 | |
| Steel Door Embossment | Smooth Steel Style Options #II-5 | |
| Steel Door Embossment | True 4-Panel Raised #II-11 | |
| Steel Entry Doors for Commercial | Limited 7 Year Warranty | |
| Steel Entry Doors for Residential | Limited Lifetime Warranty | |
| Technical Resource Guide (complete) |
CUSTOM CAPABILITIES
Our doors can be customized to fit your spec.
Give us the template, we'll make the door.
